    H beam or Box Column Moving Machine which May Move Steel Structure From one Place to Another Place

    Ask Lasest Price
    Brand Name : LUOLE
    Model Number : YGJ
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 50 sets/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    H beam or Box Column Moving Machine which May Move Steel Structure From one Place to Another Place

    Heavy H Beam Conveyor Running On Railer with Hydraulic Lift H beam 2 Synchronize Working


    Quick Details


    • This equipment is a kind of auxiliary transporting equipment for H-beam production line;
    • Beam welding structure with enough capacity and intensity;
    • After welding of one seam on work-piece, it can be transported to the other welding position;
    • Special design is available;

    1. Introduction


    This equipment is a kind of auxiliary transporting equipment for H-beam production line, 2 sets of them work at the same time, for conveying H-beam among different working position. After welding of one seam on work-piece, it can be transported to the other welding position. It has merits of high efficiency, accurate and reliable.

    It also can be used in other applications. We also welcome special requirements.


    2. Main Parameters


    ModelYGJ15
    Lift weight20T/group
    Lift stroke80mm
    System pressure16Mpa
    Oil cylinder diameterφ80mm×2
    Travel motor power1.5KW
    Travel speed≈5m/min
    Rail center distance700mm
    Above are our standard models and parameters, and it can be designed and manufactured on request.
    * We reserve the right to alter specifications without prior notice.

    3. Reference photo


    Tra-cart Beam Welding Machine with Heavy Duty Loading Capacity


    4. Comparative advantage


    • ISO9000&CE certified;
    • International warranty;
    • Punctual delivery;
    • Professional and experienced engineer team to ensure the advanced design about structure and electric;
    • Experienced and skilled workers to care for each work flow from material cutting, welding, grinding to final assembly and testing to ensure high machine quality;
    • Professional and experienced after sale service team to guarantee quick and satisfied installation, commissioning or service;
    • Optimum materials and outsourcings to ensure the best performance;
    • Commissioning and testing before delivery;
    • Factory inspection is encouraged;
