Simple Economical Type PU Hydraulic Bending Machine For PU Roof Wall Sandwich Panels

Quick details:

1. Condition: New, Type: Tile Forming Machine

2. Brand Name: LUOLE, Certification: ISO9001 and CE, Warranty: 12 months

3. Tile Type: Steel, Use: Roof, Place of Origin: Wuxi

Description

This machine is composed by frame, ram, worktable, two cylinder

Equipped with upper wedge manual crowning mechanism;

For easy feeding the workpiece, we provide front support with the machine;

The left-right balance of this machine while working is accomplished by torsion bar;

Safe fence and power break protection device are designed for the machine.

Specification

1. (a) Thickness : roof steel panel 30-150mm and wall steel panel 30-150mm.

(b) PU foam density : 40±5 kg/m³ ( or depend on requrement )

(c) Panel width : 1000mm ( or denpen on customer's requirement )

(d) Thickness of galvanizes color steel coil : 0.4mm~0.75mm

2. The production speed is different according to the panel thickness.

3. Speed of forming machine is 0~12m/min and adjustable. The length and amount of production can be set and count automatically by control panel.

4. Hydraulic material discharge stand can feed steel sheets automatically and keep accuracy during long time operation.

5. Bend saw cutter : Maximum thickness is 200mm. The suction channel is reserved for additional suction system to prevent the dust pollution.

6. The characteristic of this continuous rubber belt sandwich line is ALL parts including forming machine, lamination, conveyor, cutter and auto stacking equipment are synchronized by a central Ratio Setter control system. The user can easily control the speed through the main speed controller (VR).

Sandwich Panel Profile Drawings For Reference

Working Flow

Application

Roof Wall PU Sandwich Panel, Insulated Sandwich Panel, Prefabricated House, Prefab House, Mobile House, Cool Room...

Advantages

• High Quality
• Reliable
• Durable
• Reasonable Price
• Good after Service
• 1 Year Warranty
• More Than 10 Years Experience

Company introduction

     We are located in Wuxi city, Jiangsu province, specializes in manufacturing various types of high speed, high precision roll forming machines, with more than 15 years’ experience. It has gained highly praise by customers from all over the world, due to top quality and competitive price of the products. Company principle: top quality, low price.

      Wuxi Luole Machinery Co., Ltd is a high tech enterprise . We a professional manufacturer of cold forming equipment (especially high difficulty cold formed steel), wins the trust of customers by its honesty, pragmatic operation philosophy, advanced technology, innovative design thinking, excellent quality, superior after sales service, competitive price, etc.

Main products

    We mainly produce all kinds of roof/ wall tile roll forming machine, C purlin, Z purlin, C&Z interchangeable purlin roll forming machine, solar photovoltaic forming machine, shelf column roll forming machine, guardrail roll forming machine, cable tray roll forming machine, metal deck roll forming machine, down pipe roll forming machine, rolling shutter door roll forming machine, cut to length machine, eps/pu sandwich panel production line, slitting line, automatic stacker, etc, mainly in construction use.

After sale service

1). Engineer will give free training lessons to labors in buyer’s factory.

2). The Buyer will buy the round-trip air ticket for Engineer if visa application is approved. The buyer is also responsible to bear expenses generated, e.g. visa formalities, meals, accommodation and allowance of USD80 for engineer per day.

3). During this guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, we will provide the buyer spare parts at cost price.

4). We will charge the buyer cost price of spare parts beyond one year and provide long-term technical guide.

Photo of the factory
