    CNC Aluminum Profile Arch Bending Machine With 4.0KW Hydraulic Cutting

    Ask Lasest Price
    Brand Name : LUOLE
    Certification : CE
    Price : Discuss in letter
    Payment Terms : T/T
    • Product Details
    • Company Profile

    CNC Aluminum Profile Arch Bending Machine With 4.0KW Hydraulic Cutting

    CNC Aluminum Profile Arch Bending Machine With 4.0KW Hydraulic Cutting


    Quick details:


    1. Condition: New, Type: Tile Forming Machine

    2. Tile Type: Steel, Use: Roof

    3. Place of Origin: Wuxi, Brand Name: LUOLE


    Description


    The structure is simple and the appearance of the machine is beautiful because we adopt the shape-steel structure and process as a whole after welding.

    It has the ability of strong loading and stable operation when running the machine.

    All the components of machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.

    We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming .

    It is very easy to install the equipment and suitable for producing in the factory.

    The machine has features of low noise and high efficiency.


    specifications


    ItemDescription
    Main motor power15KW
    Forming power5.5KW
    Bending power4KW
    Cutting power4.0KW Hydraulic Cutting
    Conical power1.5KW
    Working speed
    Straight sheet15m/min
    Arch sheet13m/min
    Sewing6m/min
    Material of rollers45# steel, quenched HRC 58-62
    Material of roller shafts45# steel, adjusted
    Material of cutting bladeCr12 steel, 1MOV
    Material of curving leavesStainless steel (Long span usage though with hard friction)
    Controlling systemPLC (Omron, Japan)
    Step of rollers13 steps
    Feeding Width600mm
    Effective Width305mm
    The depth of the groove109mm
    Thickness of the coil0.8-1.5mm
    Operating factor of the panel51%
    Proper span≤24m
    Electric Standard380V, 50Hz, 3 Phases
    Passive decoilerMax.capacity of 5000kgs suitable for trailer carrying
    Trailer with 3 axles, 6 tyres
    Size9000mm*2250mm*2300mm
    Total weightAbout 9000KG

    Composition of machine


    NO.NAMEUNITQTY
    1Roll forming main machineSet1
    2Arching machineSet1
    3Manual decoilerSet1
    4Control panelSet1
    5Hydraulic stationSet1
    6Manual out tableSet4
    7Electric Seaming MachineSet1
    8Spare toolsBox1

    The profile drawing



    Machine Pictures



    Application

    This kind of machine is used for curving the corrugated steel sheet which roll formed already by steel roll forming machine. The radius of curving sheet can be adjustable.


    Advantages


    High Quality

    Reliable

    Durable

    Reasonable Price

    Good after Service

    1 Year Warranty

    More Than 10 Years Experience
