22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets

    Buy cheap 22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets from wholesalers

    Buy cheap 22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets from wholesalers
    • Buy cheap 22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets from wholesalers

    22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets

    Ask Lasest Price
    Brand Name : LuoLe
    Certification : CE
    Price : discuss in letter
    Payment Terms : TT
    • Product Details
    • Company Profile

    22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel Sheets

    22kw Hydraulic Floor Deck Roll Forming Machine For Colored / Galvanized Steel sheets


    Quick Details:


    Condition: new

    Use: floor deck, steel floor deck, building surface panels

    Brand Name: YIJIE

    Voltage: 220-450V according to customer

    Warranty: 12 months

    Product Name: Floor Deck Roll Forming Machine


    Description


    1. This machine products used in tall building structure/high building construction. It can save the steel panels and the floor loading weight.

    2. the steel floor deck roll forming machine include the automatic decoiler or manual decoiler for coils from 5 tons to 10 tons.

    3. The products can be applied in high-rise steel buildings. It can save the steel molding templates and also reduce the floor load. Under the same load capacity, it can reduce the amount of steel to achieve cost-saving.


    Specifications


    No.ItemParameter
    1Main motor power22kw*2
    2Hydraulic motor power3kw
    3Thickness of the plate1.5mm
    4Diameter of the rollerΦ100mm
    5Forming station23-32 (depend on profile drawing)
    6Working speed0-15 m/min
    7Type of cuttinghydraulic cutting
    8Suitable materialcolor steel, galvanized, aluminum

    The working flow layout:


    Decoiler–feeding guide–roll forming machine–Hydraulic cutting–Output table


    Applications


    The color steel sheet is widely used in workhouse, villa , holiday village , gardening industrial building , storage , scenic tourist area , pavilions , hotel , exhibition hall and so on.


    Advantages


    Multifunction

    Light weight

    Structural strength

    All-weather construction

    High quality and inexpensive
