    CNC Automatic Metal Ceiling Roll Forming Machine For Fold and Slit Work Piece

    CNC Automatic Metal Ceiling Roll Forming Machine For Fold and Slit Work Piece


    Quick details:


    1. Condition: New, Tile Type: Steel, Certification: ISO9001 and CE

    2. Feeding Material: color steel coils, Payment terms: T/T L/C

    3. Condition: New, Type: Tile Forming Machine


    Specifications


    1) Raw material: color steel or galvanized steel

    2) Raw material thickness: 0.2-0.8mm

    3) Material width: 1250mm

    4) Speed: 10-15m/min

    5) Roller stand: 15 groups

    6) Roller Material: 45#forged steel, with surface polished and coated with 0.05mm thickness hard chrome.

    7) Shaft Material: high grade 45#steel, heated and quenched HRC 45-50

    8) Axis diameter: 76mm

    9) Machine frame stand: welded structural steel

    10)Thickness of frame stand: 18mm

    11)Motor Power: 5.5 KW

    12)Transporting Type: Chain Transmission

    13)Cutting Type: Hydraulic cutting

    14)Hydraulic power: 3kw

    15)Material of blade: Cr12

    16)Control: Siemens PLC computer control

    17)Voltage: 380V 3PH 50HZ ( or as your requirement)


    Working fiow


    decoiling → guiding and feeding →roll forming→length cutting→run out table


    Reference Drawings



    Advantages


    1.24 hour quick response

    2.Customer oriented

    3.Credit foremost

    4.Top quality

    5.Rational price

    6.Excellent teamwork

    7.Dedicated services

    8.Accept all payment terms: TT
